Dobinsons IMS Front 2-3” Shock - Isuzu MU-X

Dobinson's IMS monotube shock absorbers are designed for next level performance over Twin Tube shocks in those hot, harsh, demanding conditions.

By utilising the monotube design, Dobinson's IMS shock absorbers are able to resist fade far longer on corrugated roads, long or hard working 4WD trips, towing or racing conditions.

Features:

•  Internal Floating Piston
• Massive 56mm & 66mm Outer Body
• 3mm Heavy Duty Wall Thickness
• Single Piece Lower Leg*
• Natural Rubber Bushings
• Triple Lip Oil Seal
• Direct Bolt-on Design
• Fully Rebuildable Design
• Monster 50mm & 60mm Bore
• Vehicle Specific Valving
• Height Adjustable Spring Seat*
• EDP Surface Protection

*Where Applicable

Suits 2-3” lifts

Adjustable Spring Seat

For 2” Lift - Front, Set X = 195mm / 7.48” ,

For Current Gen, Set  X = 195mm / 7.48”

If exceeding listed spring height BS59-560 MUST be used with IMS21-50470 to prevent coil bind.

For 3" Lift - Front,  Set  X = 195mm / 7.48”

X = Centre of Eye to Spring Seat

Models: Isuzu MU-X UCS85 (2013 to Mid 2021) Isuzu MU-X UCS40 (Mid 2021 on), Isuzu D-Max TFS85 (05/2012-Mid 2020), Isuzu D-Max TFS40 (Mid 2020-Current), Mazda BT-50 TF (Mid 2020 On), Holden Colorado RG (05/2012 on)

Fitment Position: Front

Sold As: Each

Qty per Vehicle: 2
